GE...DO型关节轴承
产品详情
| 品名： | GE...DO型向心关节球轴承 | 类别： | 滑动轴承 |
| 品牌： | TGMB | 材质： | 轴承钢 (GCr15, 100Cr6, 52100) |
| 销售电话： | 0635-2876 662 | 邮箱： | info#tgmbgroup.com |
| 简介及用途： | 向心关节球轴承是一个总称，与球和滚子轴承不同，向心关节球轴承属于滑动轴承，其细分类型包括：GE型向心关节球轴承、GAC向心推力球球轴承以及其他类型。向心关节轴承结构较为简单，主要是由内一个外圈和一个内圈组成，大部分产品为磷化处理，使内外圈表面布满结晶层，有助于产品的防锈、自润滑和耐磨。不同环境下以使用GE型向心关节球轴承为主。向心关节球轴承使用环境较为广泛，例如：农业机械、工程机械、矿山机械、包装机械、传动设备等。我厂生产的关节球轴承，除ISO标准代号外，还生产俄制关节轴承（GOST），其代号为： WCN /ШСП , WCL / ШСЛ, 具体详情请与我们联系。 | ||
| TGMB Bearing No. | Main dimensions | Basic load ratings | Mass | |||||||||
| d | D | B | C | dk | r1 | r2 | α | Dynamic | Static | |||
| mm | Deg. | C (kN) | C0 (kN) | kg | ||||||||
| GE6DO | 6 | 14 | 6 | 4 | 10 | 0.3 | 0.3 | 13 | 3.4 | 17 | 0.004 | |
| GE8DO | 8 | 16 | 8 | 5 | 13 | 0.3 | 0.3 | 15 | 5.5 | 27.5 | 0.007 | |
| GE10DO | 10 | 19 | 9 | 6 | 16 | 0.3 | 0.3 | 12 | 8.15 | 40.5 | 0.012 | |
| GE12DO | 12 | 22 | 10 | 7 | 18 | 0.3 | 0.3 | 11 | 10.8 | 54 | 0.017 | |
| GE15DO | 15 | 26 | 12 | 9 | 22 | 0.3 | 0.3 | 8 | 17 | 85 | 0.027 | |
| GE16DO | 16 | 30 | 14 | 10 | 25 | 0.3 | 0.3 | 10 | 21.2 | 106 | 0.044 | |
| GE17DO | GE17DO-2RS | 17 | 30 | 14 | 10 | 25 | 0.3 | 0.3 | 10 | 21.2 | 106 | 0.041 |
| GE20DO | GE20DO-2RS | 20 | 35 | 16 | 12 | 29 | 0.3 | 0.3 | 9 | 30 | 146 | 0.065 |
| GE25DO | GE25DO-2RS | 25 | 42 | 20 | 16 | 35.5 | 0.6 | 0.6 | 7 | 48 | 240 | 0.12 |
| GE30DO | GE30DO-2RS | 30 | 47 | 22 | 18 | 40.7 | 0.6 | 0.6 | 6 | 62 | 310 | 0.15 |
| GE35DO | GE35DO-2RS | 35 | 55 | 25 | 20 | 47 | 0.6 | 1 | 6 | 80 | 400 | 0.23 |
| GE40DO | GE40DO-2RS | 40 | 62 | 28 | 22 | 53 | 0.6 | 1 | 7 | 100 | 500 | 0.32 |
| GE45DO | GE45DO-2RS | 45 | 68 | 32 | 25 | 60 | 0.6 | 1 | 7 | 127 | 640 | 0.41 |
| GE50DO | GE50DO-2RS | 50 | 75 | 35 | 28 | 66 | 0.6 | 1 | 6 | 156 | 780 | 0.53 |
| GE60DO | GE60DO-2RS | 60 | 90 | 44 | 36 | 80 | 1 | 1 | 6 | 245 | 1220 | 1 |
| GE70DO | GE70DO-2RS | 70 | 105 | 49 | 40 | 92 | 1 | 1 | 6 | 315 | 1560 | 1.5 |
| GE80DO | GE80DO-2RS | 80 | 120 | 55 | 45 | 105 | 1 | 1 | 6 | 400 | 2000 | 2.2 |
| GE90DO | GE90DO-2RS | 90 | 130 | 60 | 50 | 115 | 1 | 1 | 5 | 490 | 2450 | 2.7 |
| GE100DO | GE100DO-2RS | 100 | 150 | 70 | 55 | 130 | 1 | 1 | 7 | 610 | 3050 | 4.3 |
| GE110DO | GE110DO-2RS | 110 | 160 | 70 | 55 | 140 | 1 | 1 | 6 | 655 | 3250 | 4.7 |
| GE120DO | GE120DO-2RS | 120 | 180 | 85 | 70 | 160 | 1 | 1 | 6 | 950 | 4750 | 8 |
| GE140DO | GE140DO-2RS | 140 | 210 | 90 | 70 | 180 | 1 | 1 | 7 | 1080 | 5400 | 11 |
| GE160DO | GE160DO-2RS | 160 | 230 | 105 | 80 | 200 | 1 | 1 | 8 | 1370 | 6800 | 14 |
| GE180DO | GE180DO-2RS | 180 | 260 | 105 | 80 | 225 | 1.1 | 1.1 | 6 | 1530 | 7650 | 18.2 |
| GE200DO | GE200DO-2RS | 200 | 290 | 130 | 100 | 250 | 1.1 | 1.1 | 7 | 2120 | 10600 | 28.3 |
| GE220DO | GE220DO-2RS | 220 | 320 | 135 | 100 | 275 | 1.1 | 1.1 | 8 | 2320 | 11600 | 35.4 |
| GE240DO | GE240DO-2RS | 240 | 340 | 140 | 100 | 300 | 1.1 | 1.1 | 8 | 2550 | 12700 | 39.4 |
| GE260DO | GE260DO-2RS | 260 | 370 | 150 | 110 | 325 | 1.1 | 1.1 | 7 | 3050 | 15300 | 51.1 |
| GE280DO | GE280DO-2RS | 280 | 400 | 155 | 120 | 350 | 1.1 | 1.1 | 6 | 3550 | 18000 | 64.6 |
| GE300DO | GE300DO-2RS | 300 | 430 | 165 | 120 | 375 | 1.1 | 1.1 | 7 | 3800 | 19000 | 77.3 |
| GE320DO | 320 | 440 | 160 | 135 | 380 | 1.1 | 3 | 4 | 4400 | 22000 | 76.4 | |
| GE340DO | 340 | 460 | 160 | 135 | 400 | 1.1 | 3 | 3.8 | 4650 | 23200 | 81.6 | |
| GE360DO | 360 | 480 | 160 | 135 | 420 | 1.1 | 3 | 3.6 | 4800 | 24000 | 84.2 | |
| GE380DO | 380 | 520 | 190 | 160 | 450 | 1.5 | 4 | 4.1 | 6300 | 31500 | 129 | |
| GE400DO | 400 | 540 | 190 | 160 | 470 | 1.5 | 4 | 3.9 | 6550 | 32500 | 133 | |
| GE420DO | 420 | 560 | 190 | 160 | 490 | 1.5 | 4 | 3.7 | 6800 | 34500 | 138 | |
| GE440DO | 440 | 600 | 218 | 185 | 520 | 1.5 | 4 | 3.9 | 8650 | 42300 | 193 | |
| GE460DO | 460 | 620 | 218 | 185 | 540 | 1.5 | 4 | 3.7 | 9000 | 45000 | 200 | |
| GE480DO | 480 | 650 | 230 | 195 | 565 | 2 | 5 | 3.8 | 9800 | 49000 | 237 | |
| GE500DO | 500 | 670 | 230 | 195 | 585 | 2 | 5 | 3.6 | 10200 | 51000 | 244 | |
| GE530DO | 530 | 710 | 243 | 205 | 620 | 2 | 5 | 3.7 | 11400 | 57000 | 289 | |
| GE560DO | 560 | 750 | 258 | 215 | 655 | 2 | 5 | 4 | 12700 | 64000 | 325 | |
| GE600DO | 600 | 800 | 272 | 230 | 700 | 2 | 5 | 3.6 | 14600 | 73500 | 407 | |
| GE630DO | 630 | 850 | 300 | 260 | 740 | 3 | 6 | 3.3 | 17600 | 88000 | 525 | |
| GE670DO | 670 | 900 | 308 | 260 | 785 | 3 | 6 | 3.7 | 19000 | 95000 | 594 | |
| GE710DO | 710 | 950 | 325 | 275 | 830 | 3 | 6 | 3.7 | 21200 | 106000 | 693 | |
| GE750DO | 750 | 1000 | 335 | 280 | 875 | 3 | 6 | 3.8 | 22800 | 114000 | 779 | |
| GE800DO | 800 | 1060 | 355 | 300 | 930 | 3 | 6 | 3.6 | 26000 | 129000 | 920 | |
| GE850DO | 850 | 1120 | 365 | 310 | 985 | 3 | 6 | 3.4 | 28500 | 143000 | 1047 | |
| GE900DO | 900 | 1180 | 375 | 320 | 1040 | 3 | 6 | 3.2 | 31000 | 156000 | 1184 | |
| GE950DO | 950 | 1250 | 400 | 340 | 1100 | 4 | 7.5 | 3.3 | 35500 | 176000 | 1420 | |
| GE1000DO | 1000 | 1320 | 438 | 370 | 1160 | 4 | 7.5 | 3.5 | 40500 | 204000 | 1742 | |
